Price: Circa £40 - £45K.
Year: 2012
Hours: 18k
Dimensions and Working Range
- Ground Clearance: 255 mm
- Undercarriage Width: 2990 mm
- Shipping Length: 11,200 mm
- Shipping Height: 3390 mm
- Upperstructure Clearance: 1465 mm
- Wheelbase: 3000 mm
- Width with Stabilizers on Ground: 4700 mm
- Tire Size: 12.00-20
- Boom/Stick Option 2: 7.6 m boom / 6 m stick
- Maximum Height: 15,200 mm
- Maximum Reach Along Ground: 13,100 mm
- Maximum Depth: 3,500 mm
Engine and Power
- Manufacturer: Liebherr
- Model: D 934 L
- Gross Power: 150 kW (204 hp)
- Displacement: 7 L
- Aspiration: Turbocharged with aftercooling, reduced emissions
Operational Specifications
- Operating Weight (without attachment): 36,015 kg (~79,400 lb)
- Fuel Tank Capacity: 580 L (153.3 gal)
- Hydraulic System Fluid Capacity: 590 L (155.9 gal)
- Operating Voltage: 24 V
- Alternator Amperage: 80 A
Swing Mechanism
- Swing Torque: 84 Nm
- Swing Speed: 8.2 rpm
Transmission and Mobility
- Maximum Speed: 20 km/h (12.5 mph)
- Undercarriage Type: Wheeled, with stabilizers for working area safety
Hydraulic System
- Pump Type: Liebherr variable displacement, swash plate, axial cam piston pumps
- Pump Capacity: 245 L/min (64.8 gal/min)
- Designed for efficient boom operation and attachment handling
Key Features
- High-tensile materials for durability and long service life
- Versatile boom and stick options for loading, unloading, and material stacking tasks
- Suitable for industrial ports, scrap yards, and heavy-duty material handling
